8
8
10. Attach an Arm Pad (6) to a Dip Arm (5) with two
M6 x 73mm Screws (18).
Repeat this step with the other Arm Pad (6).
26
26
12
12
9
Indents
19
3
28
19
9
10
9. Attach the Backrest (8) to the Top Crossbar (7)
with four M6 x 16mm Screws (27) and four M6
Washers (21).
11. Make sure that all parts have been properly
tightened before the exercise rack is used.
8
6
5
18
6
27 21
21
7
8. Attach the Pull-up Bar (9) to the Uprights (3, 28)
with two M10 x 50mm Screws (19) and two M10
Washers (26).
Make sure the indents around
the holes in the Pull-up Bar are on the side
shown. Press two Rubber Endcaps (12) into the
ends of the Uprights.
Tighten all of the M8 Nylon Locknuts (22)
used in steps 2–8.
27
