Part identification chart – Weider WEBE09140 User Manual
Page 12
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part from the PART LIST.
Note: Some small parts may have been pre-attached. If a
part is not in the parts bag, check to see if it has been pre-attached.
PART IDENTIFICATION CHART
M6 Washer (21)
M8 Nylon Locknut (22)
M6 x 16mm Screw (27)
M6 x 73mm Screw (18)
M8 x 75mm Bolt (17)
M10 x 50mm Screw (19)
M8 x 77mm Bolt (29)
M8 Washer (23)
M8 x 68mm Carriage Bolt (20)
M8 x 68mm Bolt (24)
M10 Washer (26)
