This is an advanced proprietary algorithm capable of determining the health of a battery. Specially stored
parameters allowing the Analyzer X3 or X6 to identify a battery’s range of capacity and display: Batt>60% or
Batt<60%of rated capacity . Batteries that have a low state of charge when placed in the X3 for the QT
May require a charge of up to 10 minutes before performing the QT. Up to 3 attempts to charge the battery
will be tried before a message is displayed “Discard the Battery”.
Even batteries that do not have pre-stored parameters can have a QT on, but will first be required to go
through the “ Learn Mode”. Note, first a good battery must be learned before QT can be performed .
A impedance test must be performed prior to the “Learn Mode”, and incorporated into the LEARN MODE.
SELECTING “ QUICK TEST “
RESULTS
SELECTING “ CONDITION “
AND RESULTS
FOR RESULTS
PUSH
QUICK TEST ANALYSIS
BATT>60% 0R BATT<60%
Display After “Turn On”
After the battery is placed
in the adapter
NO
NO
NO
NO
ACTION
ACTION
ACTION
ACTION
REMOVE BATTERY
PUSH FUNCTION BUTTON
until battery
specs appear
in the display
READY
EMPTY
TO PROCEED PRESS
LION 1650 MAH 7.4V
LION 1650 MAH 7.4V
HAS BEEN SELECTED
HAS BEEN SELECTED
QUICK TEST
QUICK TEST
TEST
ACTION DISPLAY
QUICK TEST ANALYSIS
9
Condition Mode
The CONDITION CYCLE serves basically two needs of Nickel based batteries, one is to reform the
Cells of a battery that hasn’t been used for an extended period of time, say for 3 or more Months.
Usually deep discharging the battery will restore the battery back to normal capacity such as the discharging
and charging cycle used in the Analyzer X3 and X6.
Lithium Ion batteries do not suffer from voltage depression, but they will not be harmed if the Conditioning
cycle is applied to them. To select the condition cycle follow the instructions below.
ACTION
Display After “Turn On”
After the battery is placed
in the adapter
NO ACTION
NO ACTION
NO ACTION
NO ACTION
NO ACTION
NO ACTION
NO ACTION
FOR RESULTS
PUSH FUNCTION BUTTON
until battery
specs appear
in the display
PUSH
PUSH
PUSH
CYCLE/AUTO/CONDITION
CYCLE/AUTO/CONDITION
HAS BEEN SELECTED
CYCLE 1
CONDITION TO 80%
CONDITION TO 80%
HAS BEEN SELECTED
TESTING
READY
CONDITION - DONE 1
CAP= 85% 595 MAH
EMPTY
TO PROCEED PRESS
NICD 700 MAH 7.2V
NICD 700 MAH 7.2V
HAS BEEN SELECTED
QUICK TEST
Secondly this mode will eliminate MEMORY EFFECT better known as VOLTAGE DEPRESSION.
With the X3 and X6, the percentage of the rated capacity of the battery being CONDITIONED is set at 80%, the 80%
is set at the factory and can be modified with the use of optional software.
12
