Windsor Sensor XP 15 SRXP15IA User Manual
Page 15
PARTS LIST / XP15 / 230/240V
POS
PRODUCT
CODE
PRV NO.
DESCRIPTION
100
86144350
5486WI
POWER HEAD COVER XP 15
101
86141430 5008BLU
EXHAUST
FILTER
CATCH
102
86141450 5143
EXHAUST
FILTER
103
86141410 5007BLU
EXHAUST
FILTER
COVER
104
86146160
5729UL
SWIVEL NECK ASSEMBLY
105
86143210
5495UL
MALE CONTACT HOLDER
106
86147030
0102
SCREW M3,9x13 MM DIN 7981
107
86139230 2494
CABLE
CLAMP
108
86145120 5101
SLEEVE
109
86146090
5178
SWIVEL NECK SUPPORT RIGHT
110
86146150
5728
SWIVEL NECK SUPPORT LEFT
111
86146130
5717
SWIVEL NECK BEARING
112
86137650 5193ER
12V
POWER
SUPPLY
113
86144650 5205
RIBBON
CABLE
114
86138650
5102BLU
BRUSH ROLLER RELEASE
115
86145290 5103
SPRING
116
86137980
5051HG
AXLE ASSEMBLY GRY
117
86293260
5059OR
FOOT PEDAL, ORANGE
118
86137990 5053
AXLE
119
86146670 5819HG
WHEEL,
GRY
120
86146570
2010
WHEEL RETURN SPRING
121
86140000
2014
CLAMP CONNECTING ROD (AXLE)
122
86138170
5287BLU
BEARING BLOCK RIGHT HAND
123
86138810
5290WI
BRUSH ROLLER SR 15
124
86138970
5230HG
BUMPER SR15 GRY
125
86144730
5155HG
RUBBING PLATE GRY
126
86137720 5172OR
ACCESS
DOOR,
ORANGE
127
86138000
5303
AXLE, ACCESS DOOR
128
86145330
5304
SPRING, ACCESS DOOR
129
86142560 5154HG
HINGE
GRY
130
86147150
0100
SCREW 2.9 x 9.5
131
86147170
0176
SCREW AM 4 x 30
132
86143920
5174HG
PILE ADJUSTMENT WHEEL GRY
133
86145080
5060ER
SERVO MOTOR WITH GEAR BOX
134
86138320 5413HG
BOTTOM
PLATE
135
86148340
5414HG
BOTTOM PLATE SR15
136
86144950
5400-2
SEALING STRIP 15”
137
86146790
5401
WIRE TIE, BOTTOM PLATE, OUTER
138
86146800
5402
WIRE TIE, BOTTOM PLATE, CENTER
139
86144850
0197
SCR, M4X12 MM W/WASHER
140
86139910
5321UL
CHASSIS SR15 GRAY
141
86139410
05118S
CARBON BRUSH SET 230/240V
-
-
5470
MOTOR, VAC 1000W / 230V
-
86143640
5471
MOTOR, VAC 1000W / 240V
142
86144710 5100
RUBBER
MOUNTING
143
86143620
5462
MOTOR PULLEY 2MR
144
86145470 5129
SUPPORT
LEVER
145
86145460 5107
SUPPORT
SPRING
146
86143570
5112SW
MOTOR PULLEY COVER
147
86140160
5740ER
COMPUTER CONTROLLER, 115 & 230v
148
86147160
0107
SCREW 2.9 x 13
149
86147190
0143
WASHER 3,2
150
86140760
5173SW
COVER (SWIVEL NECK)
151
86145060
5465
SENSOR (WITH RED RING)
152
86147050
0104
SCREW M3.9 x 25MM
153
86138240 5463
BELT
2MR-310-6
154
86005000
5110
BELT HTD-II, 219 3M
155
86138210
5767HG
BEARING BLOCK LEFT HAND, CPL
156
86147040
0103
SCREW M3,9 X 16 MM DIN 7981
157
86147050
0141
WASHER, LOCK
158
86143560
5018UL
MOTOR COVER, GREY
159
86138690
5239BLU
BRUSH ROLLER RELEASE
160
86144920
5244HG
SEAL BEARING GRY
161
86138780
5288BLU
BRUSH COVER GRY/BLU
162
86138810
5290WI
BRUSH, ROLLER SR 15
163
86145110 5246
SHAFTEXTENSION,
CPL.
164
86143580 5117
MOTOR
PULLEY
