Page 12

Figure 6

Step 7

Add front panel

You will need: front panel and two plastic buttons.

Turn frame assembly right side up.

Align the panel with the holes in the frame and insert the
plastic buttons through the front panel and frame. Figure 6.

View from rear

of barbecue

Plastic buttons

Step 6

Insert casters

You will need: frame assembly and two casters.

Push the casters firmly into the inserts in the ends of the
caster legs. Figure 5.

Figure 5
