Whirlpool GCEM2990TQ0 - Manual (Page 7)

CABINET PARTS
7
For Model: GCEM2990TQ0
(White)
W10119635
Illus. Part
No. No. DESCRIPTION
1 3394083 Clip, Front Panel
2 388326 Screw,
8−18 x 1−1/4
3 8541400 Bracket, Cabinet
4 343641 Screw, 10−16 x 1/2
6 3403630 Plug, Strike Hole
7 3393008 Screw, 10−16 x 1/2
8 697776 Screw, 10−32 x 5/8
9 3397659 Terminal Block
10 697773 Screw, 6−20 x 7/8
15 3396795 Cover, Block
16 8066217 Hinge, Top (2)
18 3396805 Panel, Rear
20 690363 Lock, Front Top
21 98234 Clip, Ground (2)
22 3406129 Seal & Bearing
Assembly
23 693995 Screw, Hex
Washer Head
24 3403444 Front Panel
Assembly
25 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
26 3404413 Plug, Hinge
Hole
28 8530603 Cabinet
(Includes
Illus. 3)
30 3406109 Door Switch
Assembly
34 685203 Clip, Felt Pad (2)
37 3389441 Catch, Door
38 8066206 Motor Assembly
39 348780 Base, Motor
40 8066065 Belt, Drive
41 3400500 Bolt,
5/16−18 x 3/4
44 691366 Idler & Pulley
Assembly
45 3404162 Clamp, Motor
46 660658 Clamp, Motor
48 8066184 Pulley
52 3405246 Seal, Door
54 3403431 Strike, Door
58 3405514 Hinge & Pin
Assembly (2)
59 342055 Screw, 8−18 x 1/2
61 3402341 Door, Rear
63 3402335 Door, Front
64 3405184 Handle, Door
65 279318 Terminal,
Tinned & Brass (3)
66 279393 Screw Kit
(For Terminal
Block)
