Body / chassis assembly (ghs models), 1 5103 seat 1, 2 7203 seat spring plate 1 – Walker MDD User Manual
Page 6: 3 7223 compression spring (1/2 x 1) 2, 4 7845 rubber bumper (1.375 od x .63) 2, 5 7846 washer (3/8 id x 1-1/4 od x 1/8) 2, 6 7204 shoulder bolt, seat mount 2, 7 7440-5 shock mount (1-1/4 x 3/4) 2, 8 ns recovery tank mount 1, 9 7047-5 mount plate 1
Body / chassis assembly (ghs models), 1 5103 seat 1, 2 7203 seat spring plate 1 | 3 7223 compression spring (1/2 x 1) 2, 4 7845 rubber bumper (1.375 od x .63) 2, 5 7846 washer (3/8 id x 1-1/4 od x 1/8) 2, 6 7204 shoulder bolt, seat mount 2, 7 7440-5 shock mount (1-1/4 x 3/4) 2, 8 ns recovery tank mount 1, 9 7047-5 mount plate 1 | Walker MDD User Manual | Page 6 / 72
