Specifications
Power Input/Output (IPS-400):
Voltage: 100 - 120 VAC, 50/60 Hz
AC Input: 15 Amps Maximum
AC Inlet: IEC-60320-C14
AC Outlets: Four (4) NEMA 5-15 Outlets
Current Load: 15 Amps Max. (Total)
Power Input/Output (IPS-400-CE):
Voltage: 208 - 240 VAC, 50/60 Hz
AC Input: 10 Amps Maximum
AC Inlet: IEC-60320-C14
AC Outlets: Four (4) IEC60320-C13 Outlets
Current Load: 10 Amps Max. (Total)
Physical/Environmental:
Size:
Width: 19.0" (48.2 cm)
Depth: 4.25" (10.8 cm)
Height: 1.75" (4.5 cm) one rack U
Weight: 10 lbs (4.5 Kg) Shipping Weight
Operating Temperature: 32˚F to 122˚F
(0˚C to 50˚C)
Humidity: 10% to 90% RH
Agency Approvals:
Control Ports:
Ethernet Port: 10Base-T
Console Port: DB-9M, RS-232C
RS232 Coding: Serial ASCII, 7/8 Bits,
300-38.4 Kbps.
Security and Co-Location Features
Access to the IPS-400 command mode is password protected
to prevent unauthorized users from invoking sensitive switching
and configuration functions. Both the Web Browser Interface and
Command Line Interface require the user to enter a password before
allowing access. Passwords transmitted via web browser use 64-bit
encryption techniques to ensure that passwords remain protected
and access to your equipment remains secure. Telnet control can
be user-defined to a discrete TCP port, or completely turned off to
ensure that no unprotected port is present.
The IPS-400 also features two different levels of operational
passwords; the System Administrator Level and the User Level.
The Administrator Level provides access to all configuration and
switching functions, while the User Level is limited to switching
functions only. Each outlet can have a unique User Level password.
5 Sterling • Irvine • California 92618-2517
TOLL FREE (800) 854-7226
TEL (949) 586-9950
FAX (949) 583-9514
© Copyright 2005 Western Telematic, Incorporated
NetReach is a trademark of
Western Telematic, Incorporated
System Status Screen
IPS-400
IPS-400-CE
FCC
