Wolf Appliance Company CT15E User Manual
Page 7
7
2"*
min (51)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
18"
(457)
19
1
/
4
"
(489)
COOKTOP CUT-OUT
DEPTH
2
1
/
2
"
min
(64)
36"
(914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
13"
max
(330)
30"
(762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
24"
min
(610)
*Minimum clearance from both side edges of cooktop cut-out to combustible materials up to 18" (457) above countertop. **Minimum clearance
from rear edge of cooktop cut-out to combustible materials up to 18" (457) above countertop.
4"
(102)
10"
(254)
3
1
/
2
"
(89)
3
3
/
4
"
min
(95)
30-INCH OVEN OPENING
E
28
3
/
8
"
(721) COOKTOP
CUT-OUT WIDTH
28
3
/
8
"
(721)
COOKTOP CUT-OUT WIDTH
FRONT OF COUNTERTOP
2
1
/
2
"
min
(64)
19
1
/
4
"
(489)
COOKTOP
CUT-OUT DEPTH
33"
(838) RECOMMENDED
CABINET WIDTH
30"
min (762)
2"**
(51)
Overall Dimensions
Countertop Cut-Out
21"
(533)
OVERALL
DEPTH
30"
(762)
OVERALL WIDTH
5"
(127)
3
3
/
4
"
(96)
CONDUIT
F R A M E D
M O D E L C T 3 0 E
The illustrations below provide installation
specifications for Model CT30E.
For ease of installation, 33" (838) cabinets are
recommended for installation of Model CT30E.
A Wolf 30" (762) or 36" (914) built-in single
oven may be installed below Model CT30E. For
this installation, unless you are using cabinets
deeper than 24" (610), it is recommended that
the electrical supply be placed in the base
cabinet to the right of the oven.
Refer to installation instructions provided with
the built-in oven for additional specifications.
If Model CT30E is installed above cabinets, the
electrical placement is not critical. A grounded
electrical box should be located within 4'
(1.2 m) of the right rear of the cooktop.
IMPORTANT NOTE: Do not block the cooling
fan located at the bottom of the cooktop.
IMPORTANT NOTE: Installation specifications
for Model CT30E-208/S are identical to Model
CT30E. Only the electrical specifications differ.
M O D E L C T 3 0 E
Overall Width
30" (762)
Overall Height
3
3
/
4
" (96)
Overall Depth
21" (533)
Minimum Cabinet Depth
22
3
/
4
" (578)
Minimum Height Clearance*
4" (102)
Cut-Out Width
28
3
/
8
" (721)
Cut-Out Depth
19
1
/
4
" (489)
I N S T A L L A T I O N S P E C I F I C A T I O N S – M O D E L C T 3 0 E
Dimensions in parentheses are in
millimeters unless otherwise specified.
I N S TA L L AT I O N
I N S T R U C T I O N S
*Minimum 5
3
/
4
" (146) clearance is required
between countertop and any combustible
surface directly below the cooktop.
For detailed conduit dimensions, refer to
the illustration on page 5.
Dimensions may vary to ±
1
/
8
" (3).
