Wrangler JEEP P5063 - Manual (Page 10)

P5063pr-0923
10
ASSEMBLY F
P5063a-0920
• Position the steering wheel with the large opening UP.
• Position the steering column so that the bend is UP, as shown.
• Fit the steering column through the center hole in the
steering wheel.
Steering Wheel
Large Opening
Steering Column
Bend
Upright
Large Opening UP
• Place the dashboard on top of the vehicle, as shown.
• Insert five #10 x 1" screws into the dashboard and tighten.
Dashboard
4
5
3
• Insert a #10 x 1" screw into the back edge of the seat. Tighten
the screw.
• Position the roll bar so that it bends toward the back end of
the vehicle.
• Insert and "snap" the roll bar into the large holes in the top side
of the vehicle, as shown.
• Pull up on the roll bar to be sure it is secure.
Roll Bar
Hole
Hole
2
#10 x 1" Screw
