weber 600 - Manual (Page 8)

8
CHECK THAT BURNERS
ARE OFF
Figure 14
You will need: one burner control knob.
Valves are shipped in the off position, but you should
check to be sure. Put the knob on each valve. Check by
pushing down and turning clockwise. If they do not turn,
they are OFF. Proceed to the next step. Figure 14.
Figure 15
Male fitting
To barbecue
Quick disconnect
engaged
Collar
Locking shut off
Outside house wall
(a)
(b)
CONNECT GAS SUPPLY
ƽ
WARNING
Make sure all burner control knobs are in
the OFF position, including the side burner,
if the barbecue has a side burner.
To connect the natural gas supply, slide back the collar
of the quick disconnect. Push male fitting of the hose
into the quick disconnect, and maintain pressure.
Figure 15 (a). Slide the collar closed. Figure 15 (b). If it
does not engage or lock, repeat procedure. Gas will not
flow unless the quick disconnect is properly engaged.
