INSTALL BOTTOM TRAY
You will need: Bottom tray, catch pan holder, catch pan,
and one drip pan.
Figure 8
Figure 9
Note: It may be easier to install the catch pan holder by
removing the catch pan from the holder.
Hook the ends of the catch pan holder into the hole in the
bottom tray. Figure 9.
Figure 10
Slide the bottom tray into the mounting slots under the
bottom of the cooking box with the finger grip of the catch
pan toward you. Figure 10.
ƽ
CAUTION: Do not line the bottom tray with aluminum
foil. It can cause grease fires by trapping the grease
and not allowing grease to flow into the catch pan.
6
ADD COOKING GRATES
Figure 7
You will need: two (Summit 400) or three (Summit 600)
cooking grates.
The open “U” of the cooking grill goes down. Set the
cooking grates in place next to each other. Figure 7.
