B-6
(1) (2)
(1)
(2)
(3)
Add fuel gauge
You will need: fuel gauge, two wing nuts and two nylon
washers.
1) Slip the bolts on the back of the fuel gauge
through the two small holes in the cylinder panel.
2) Add washers to the bolts, then wing nuts, and
tighten with your fingers.
Install igniter
Note - The igniter wires are already attached to the
Gas Catcher Ignition Chamber and the igniter. This
was done to factory test the ignition system.
The igniter lock nut is on the igniter.
1) Loosen the igniter lock nut.
2) Insert the top of the igniter up through the large
part of the keyhole in the frame brace. Slide the
igniter into the small part of the keyhole.
3) Tighten the igniter lock nut back onto the igniter.
Note - If the igniter works loose, carefully tighten the
igniter lock nut with an adjustable wrench or pliers.
