Windsor Sensor SRS12 - Manual (Page 16)

PARTS LIST / SENSOR S12 / 120V
POS
PRODUCT
CODE
PRV NO. DESCRIPTION
100 86144140 2831WI POWER HEAD COVER S 12, CPL.
101 86141400 2846 EXHAUST FILTER
102 86141380 2820BL EXHAUST FILTER COVER
103 86145910 2827UL SWIVEL NECK ASSEMBLY
104 86143180 2886 MALE CONTACT HOLDER
105 86139230 2494 CABLE CLAMP
106 86147030 0102 SCREW M3, 9x13 DIN 7981
107 86139100 2835 BYPASS VALVE
108 86142790 0869 INTERNAL CABLE
109 86145900 2825 SWIVEL NECK BEARING
110 86145890 2824 SWIVEL NECK SUPPORT R.H.
111 86146110 5479 SWIVEL NECK SUPPORT L.H.
112 86146130 5717 SWIVEL NECK BEARING
113 86143800 2890ER PCB POWER SUPPLY
114 86142780 0864 INTERNAL CABLE, RIBBON
115 86138820 5713BL BRUSH ROLLER RELEASE
116 86145290 5103 SPRING
117 86137980 5051HG AXLE ASSEMBLY GRY
118 86137990 5053 AXLE
119 86293260 5059OR FOOT PEDAL, ORANGE
120 86146570 2010 WHEEL RETURN SRPING
121 86146670 5819HG WHEEL, GRAY.
122 86140000 2014 CLAMP CONNECTING ROD AXLE
123 86004950 5010WI BRUSH ROLLER 12”
124 86138170 5287BLU BEARING BLK, RH SR12 BLU/GRY
125 86144700 2869HG RUBBING PLATE
126 86137700 2868OR ACCESS DOOR
127 86138000 5303 ACCESS DOOR AXLE
128 86145330 5304 ACCESS DOOR SPRING
129 86143850 2861 PILE ADJUSTMENT AXLE
130 86143920 5174hg PILE ADJUSTMENT WHEEL GRY
131 86137920 2849 AXLE CLAMP
132 86144860 01010 SCREW M4 x 16, DIN 7985
133 86140620 2860HG COVER
134 86146220 2833 THRUST MEMBER
135 86143860 2862HG PILE ADJUSTMENT KNOB
136 86146230 2834 THRUST MEMBER
137 86140010 2856 CLAMP
138 86145250 2867 SPRING
139 86139730 2821HG CHASIS SSRS 12, CPL
140 86138280 5411HG BOTTOM PLATE,FRT,CLP,GRY, SR12
141 86144520 2829HG REAR BOTTOM PLATE SRS12, CPL
142 86144850 0197 SCR, M4 X 12 MM W/WASHER
143 86146790 5401 WIRE TIE, BOTTOM PLATE, OUTER
144 86146800 5402 WIRE TIE, BOTTOM PLATE, CENTER
145 86138940 5005HG BUMPER GRY (2PC SR12)
146 86139400 05117S CARBON BRUSH SET 100-120V
- 86146210 05135ST THERMO SWITCH VAC
- 86143630 5469 MOTOR 1000 W / 120 V
147 86143620 5462 VACUUM MOTOR PULLEY 2MR
148 86144710 5100 RUBBER MOUNTING
149 86143490 2826BL MOTOR COVER
150 86140610 2839SW COVER FOR AIR CHANNEL
151 86145470 5129 SUPPORT LEVER
152 86145460 5107 SUPPORT SPRING
153 86143570 5112SW MOTOR PULLEY COVER
154 86140150 2881ER COMPUTER CONTROLLER
155 86147160 0107 SCREW 2.9 x 13
156 86147190 0143 WASHER 3.2
157 86145050 5464 SENSOR X4 CPL
158 86143580 5117 MOTOR PULLEY
159 86147050 0104 SCREW M3.9 x 25 MM
160 86138240 5463 BELT 2MR-310-6
161 86005000 5110 BELT HTD-II-6, 219 3M
162 86138200 5766HG B
EARING BLOCK L.H. CPL.
163 86147040 0103 SCREW C 3.9 x 16 DIN 7981
164 86146540 0140 WASHER
165 86147170 0176 SCREW M4 X 30
