Weil-McLain UO-3 CV - Manual (Page 24)

6104BAFG R0
6
Page 23
# Part No. Description
1 Burner Housing Assembly
2 Specify* Air Band - Specify # of slots
3 Specify* Air Shutter - Specify # of slots
4 21807U Valve Cordset
Not Shown 21887U PD Timer Delay Cordset
5 2184404U CleanCut Pump
6 5394 Copper Oil Line - 8”
7 3666 Splined Nut
8 3493 Escutcheon (F & L1/L2 heads)
9 2139 Hole Plug
10 2454 Coupling
11 31231U (AFG)
31841U (AF) Air Guide (AFG)
Air Inlet Bell (AF)
12 2999U (AFG)
2459U (AF) Blower Wheel (AFG)
Blower Wheel (AF)
13 21805U
4189 PSC Motor
Mounting Screws
14 5770 Electrical Box
15
7505P Replaces R7184P - Pre and Post-
time**
# Part No. Description
16 51771U Igniter & Base Plate
17 & 18 51304 Igniter Gasket Kit
19 5880 Low Firing Rate Baffl e
20 7006U Cad Cell Detector
21
5940 Electrode Kit - M Head up to 9”
22 Specify *
3 811
Welded Flange
Gasket Only
23 Specify * Retention Head Assembly
24 Specify * Nozzle Line Electrode & Head Assembly
25 5685 Pedestal Kit
26 2182602U Solenoid Valve Kit (delay)
27 32395U Cover
* Contact your Beckett Representative for part num-
ber and pricing.
** Contact your Beckett Representative for available
pre and post time settings.
For best performance specify genuine
Beckett
replacement parts
