PART IDENTIFICATION CHART

M10 Washer (29)

M6 Washer (31)

M8 Nylon Locknut (43)

M10 Spacer (42)

M8 x 35mm Carriage Bolt (36)

M8 x 68mm Bolt (28)

M8 x 55mm Bolt (22)

M10 x 168mm Bolt (40)

M10 x 67mm Bolt (46)

M8 Washer (41)

M10 Nylon Locknut (45)

M8 x 16mm Bolt (44)

M6 x 50mm Screw (38)

M6 x 16mm Screw (10)

M6 x 38mm Screw (14)

M10 x 55mm Bolt (49)

Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
