PARTS LIST / SENSOR XP18 / 120V
POS
PRODUCT
CODE
PRV NO. DESCRIPTION
100 86144360 5487WI POWER HEAD COVER XP 18
101 86141430 5008BLU EXHAUST FILTER CATCH
102 86141450 5143 EXHAUST FILTER
103 86141410 5007BLU EXHAUST FILTER COVER
104 86146400 5727UL SWIVEL NECK ASSEMBLY
105 86143200 5258UL MALE CONTACT HOLDER
106 86147030 0102 SCREW M3,9x13 MM DIN 7981
107 86139230 2494 CABLE CLAMP
108 86145120 5101 SLEEVE
109 86146090 5178 SWIVEL NECK SUPPORT RIGHT
110 86146150 5728 SWIVEL NECK SUPPORT LEFT
111 86146130 5717 SWIVEL NECK BEARING
112 86137660 5203ER 12V POWER SUPPLY 120V 3 WIRE
113 86144650 5205 RIBBON CABLE
114 86138650 5102BLU BRUSH ROLLER RELEASE
115 86145290 5103 SPRING
116 86137980 5051HG AXLE ASSEMBLY GRY
117 86293260 5059OR FOOT PEDAL, ORANGE
118 86137990 5053 AXLE
119 86146670 5819HG WHEEL, GRY
120 86146570 2010 WHEEL RETURN SPRING
121 86140000 2014 CLAMP CONNECTING ROD (AXLE)
122 86138170 5287BLU BEARING BLOCK RIGHT HAND
123 86138770 5276WI BRUSH ROLLER SR 18
124 86138990 5231HG BUMPER SR18 GRY
125 86144730 5155HG RUBBING PLATE GRY
126 86137720 5172OR ACCESS DOOR, ORANGE
127 86138000 5303 AXLE, ACCESS DOOR
128 86145330 5304 SPRING, ACCESS DOOR
129 86142560 5154HG HINGE GRY
130 86147150 0100 SCREW 2.9 X 9.5
131 86147170 0176 SCREW M4 X 30
132 86143920 5174HG PILE ADJUSTMENT WHEEL GRY
133 86145080 5060ER SERVO MOTOR W/GEAR BOX
134 86141830 5415HG FRONT BOTTOM PLATE
135 86144540 5416HG REAR BOTTOM PLATE
136 86144960 5400-3 SEAL STRIP SR18
137 86146790 5401 WIRE TIE, BOTTOM PLATE, OUTER
138 86146800 5402 WIRE TIE, BOTTOM PLATE, CENTER
139 86144850 0197 SCR, M4X12 MM W/WASHER
140 86139910 5322UL CHASSIS SR18 GRAY
141 86139400 05117S CARBON BRUSH SET 100/120V
- 86146210 05135ST THERMO SWITCH VAC
- 86143630 5469 MOTOR 1000W / 120V
142 86144710 5100 RUBBER MOUNTING
143 86143620 5462 MOTOR PULLEY 2MR
144 86145470 5129 SUPPORT LEVER
145 86145460 5107 SUPPORT SPRING
146 86143570 5112SW MOTOR PULLEY COVER
147 86140160 5740ER COMPUTER CONTROLLER, 115 & 230v
148 86147160 0107 SCREW 2.9 X 13
149 86147190 0143 WASHER 3.2
150 86140760 5173SW COVER (SWIVEL NECK)
151 86145060 5465 SENSOR (WITH RED RING)
152 86147050 0104 SCREW M3.9 X 25 MM
153 86138240 5463 BELT 2MR-310-6
154 86005000 5110 BELT HTD-II, 219 3M
155 86138210 5767HG BEARING BLOCK LEFT HAND CPL.
156 86016900 0103ER SCREW C 3.9 X 16
157 86146550 0141 WASHER, LOCK
158 86143560 5018UL MOTOR COVER, GREY
159 86138690 5239BLU BRUSH COVER RELEASE
160 86144920 5244HG SEAL BEARING GRY
161 86138780 5288BLU BRUSH COVER GRY/BLU
162 86138770 5276WI BRUSH ROLLER, SR 18
163 86145110 5246 SHAFT EXTENSION
164 86143580 5117 MOTOR PULLEY
