WIRING GROUP-CONTROL PANEL GROUP
SGJ32 86037680 01/03/07 5-47
3
33 ORG
22 RED
34 LT BLU
2
36 RED
35 RED
30 RED
29A GRN
26A BLK
27A ORG
28A BLU
31A WHT
32A RED
1
LCD
1 WHT/BLU
2 BLK
3 LTBLU
4 LTBLU
7 YLW
8 GRN
10 LTBLU
11 WHT
12 LTBLU
15 ORG
16 BLU
12A LTBLU 12B LTBLU
7A YLW
4A LTBLU
ONE
TOUCH
4B LTBLU
2A BLK
8A GRN
BRUSH
PRESSURE
11A WHT
SOLUTION
CONTROL
16 LTBLU 16 BLU 16 BLU
16 LTBLU
16 BLU
16 BLU 16 BLU
DISPLAY TOGGLE
VACUUM/SQUEEGEE
1A WHT-BLU
15A ORG
16 LTBLU
16 LTBLU
10A LTBLU
10B LTBLU
16 LTBLU
3A LTBLU
3B LTBLU
HEAD LIGHT RECYCLE
35A RED
KEY
SWITCH
36A RED
16 LTBLU
EMERGENCY
STOP SWITCH
E STOP
30A RED 32 RED
INDICATES OPTIONAL ACCESSORY
