Part identification chart – Weider 831.15999.1 User Manual
Page 5
5
This chart is provided to help you identify the small parts required for assembly. The number in parentheses
below each part refers to the key number of the part from the PART LIST near the end of this manual. Note: If a
part is not in the hardware kit, check to see if it has been preattached.
M8 Locknut (17)
M6 x 16mm Screw (29)
M10 Locknut (33)
M10 x 63mm Bolt (32)
M6 x 38mm Screw (30)
M8 Washer (16)
M10 Washer (34)
M6 Washer (26)
M10 x 137mm Bolt (36)
M8 x 55mm Bolt (18)
M10 x 120mm Bolt (19)
M8 x 43mm Bolt (39)
M8 x 42mm Carriage Bolt (37)
PART IDENTIFICATION CHART
