Page 5
5
INSTALLER/CONFIGURATION MENU
Press and hold the Menu button for at least 5 seconds. The display will show item #1 in the table below. Press Menu to ad-
vance to the next menu item. Press
or
to change a menu item options.
INSTALLER/CONFIGURATION MENU
MENU
REF.
PRESS
BUTTON
DISPLAYED
(FACTORY DE-
FAULT)
Press
or
to
select from listed op-
tions
COMMENTS
1
MENU
(GAS)
ELE
GAS setting: furnace controls the blower
ELE setting: thermostat controls the blower
2
MENU
CS (3)
0, 1, 2, 4, 5, 6
Selects Cool Savings
Value 1 (low) to 6 (high),
Value 0 disables feature
3
MENU
E (On)
OFF
Selects Energy Management Recovery (EMR)
On or OFF.
4
MENU
CR Heat (ME)
SL, FA
Adjustable Anticipation:
Selects heating cycle rate for MS or SS in #1 only
5
MENU
CR Cool (ME)
SL, FA
Adjustable Anticipation:
Selects the cycle rate for cooling
6
MENU
CL (OFF)
CL On
Compressor Lockout Time
7
MENU
Cool Off, Heat Auto
Heat Auto Cool Off,
Heat Off with Fan icon,
Heat Off without Fan icon
Cool Off, Auto Off
System Mode Confi guration
with Automatic Changeover capability
8
MENU
dL (On)
dL OFF
Selects Display Light On or OFF
9
MENU
0
(current temperature)
1 HI, 2 HI, 3HI, 4 HI,
1 LO, 2 LO, 3 LO, 4 LO
Adjustable Ambient Temperature Display
10
MENU
°F
°C
Selects Fahrenheit/Celsius Temperature Display
11
MENU
(On) b
OFF
May select Beeper OFF to stop audible
key feedback
12
MENU
P (7)
3, 0
Defaults 7-day programming (P7) but non-
programmable (0) or 5/1/1 programming (P3)
is available on most models.
13
MENU
PS (4)
2
Selects Program periods per day:
4 = Morn, Day, Eve, Night
2 = Day, Night
14
MENU
Heat AS (On)
OFF
Automatic Schedule for heat mode
15
MENU
Cool AS (On)
OFF
Automatic Schedule for cool mode
16
MENU
Remote (OFF)
On
Selects Remote Sensor On/OFF
MENU
Remote
(In)
Outdoor
Selects Remote Sensor to outdoor
NA is Remote Sensor OFF
MENU
Indoor Loc
(On)
OFF
Selects Local Sensor (in thermostat) to OFF.
N/A if Remote is selected to Outdoor
17
MENU
dS (On)
Off
Selects Automatic Daylight Saving Time option
18
MENU
(OFF)
Keypad Lockout
L, P, Limit
Selects one of 3 Keypad Lockout confi gurations
L - Total Keypad Lockout
P - Partial Keypad Lockout
(Up and Keys still work)
Limit - Limited Temperature RANGE
MENU
(000)
Keypad Lockout
1-999
Selects personal lockout code. 000 is NOT A
VALID CODE.
19
MENU
L Heat
(99)
L 62 to L 98
Selects Limited HEAT Range Temperature
20
MENU
L Cool
(45)
L 46 to L 82
Selects Limited COOL Range Temperature
