CONTROL PANEL AND SEPARATOR PARTS
5
For Model: CSP2760TQ0
(White)
W10128963
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
8576522 Harness, Wire (2)
1A
692998 Receptacle (2)
2
3400000 Screw, 10−24 x 3/8
3
3391018 Tie, Cable
4
697776 Screw, 10−32 x 5/8
5
98139 Screw, 8−32 x 5/16
6
3390115 Bracket, Timer (2)
7
3389668 Timer (Includes
4−Pin Cam) (2)
8
Cam
3387974 3−Pin (60 Min.)
339855 4−Pin (45 Min.)
343777 6−Pin (30 Min.)
Also Available
339854 9−Pin (20 Min.)
339853 12−Pin (15 Min.)
9
385421 Funnel, Coin (2)
10
303921 Screw, 8−32 x 3/8
11
3954761 Plate,
Chute Adapter (2)
(Includes
Illus. 9)
12
3979100 Panel, Control
13
8565384 Insert, Decorative
14
Lamp, Indicator
3979325 Red
3979326 Amber
3979327 Blue
15
354239 Rivet (4)
16
8283296 Wire Jumper (2)
(Light & Switch)
17
8316437 Switch,
Pushbutton (2)
18
8316433 Pushbutton
19
3397659 Block, Terminal (2)
20
8539882 Jumper Wire
21
279318 Terminal, Brass
Tinned (3)
(Includes
Illus. 24)
22
3400500 Bolt,
5−16 x 18 (2)
23
3978853 Collar
24
279393 Terminal Block
Screw Kit (For
Terminal Block)
25
3400029 Nut, 10−32 (6)
26
3400094 Screw, 10−32 x 3/8
27
3396795 Cover, Terminal
Block (2)
28
3390443 Retainer,
Terminal (2)
29
3401699 Jumper, Wire
(Ground)
Following Parts Supplied
On Whirlpool Coin
Equipped Models Only
30
96435 Screw, 10−32 x 3/8
31
8316520 Slide Mechanism
(Vertical 8−Coin)
(Dollar Vend)
Inserts
(Not Shown)
8316264 Blank
8316265 25¢
32
8316525 Money Box W/Lock
33
Key (Money Box)
(When Ordering,
Specify Vendor
and Key Number)
34
8316526 Security Lock/Key
and Cam Assembly
35
Key (Service Door)
(When Ordering,
Specify Vendor
and Key Number)
36
8318517 Bolt, Slide
Mechanism
39
3390424 Extension,
Slide
40
3390615 Screw & Cam
Bag Assembly
Coin Mechanism Parts May Be
Ordered From Whirlpool Or
The Vendor(s) Listed Below
ESD
270 New Jersey Dr.
Fort Washington, PA
19034
1−800−523−1510
@
info
esdcoin.com
