COMPONENTS
SABER (SC) 86038350 01/29/07
3-4
1. Control
Panel
2. Control Handle
3. Recovery Tank
4. Recovery Tank Drain Hose
5. Scrub Head
6. Scrub Brush Access Cover
7. Solution Tank
8. Solution Tank Cover
9. Solution Tank Drain Hose
10. Solution Strainer
11. Solution Tank Support Arm
12. Squeegee
13. Vacuum Motor
8
2
1
4
9
12
3
10
13
11
5
7
6
