PUMP GROUP (200 PSI)
NINJA INTL 86038610 03/29/07 5-6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233150 20042 5 CLAMP, 3/8 HOSE (D-SLOT)
2 86280750 151-38A 2 HOSE, 1/2 WIREBOUND X 21”
3 86068520 40028 2 HOSEBARB, 1/4 MPT X 1/2 DL
4 86199230 250-33 1 BPR PUMPTEC NINJA 200PSI
5 86005590 56014 1 NIPPLE, 1/4 CLOSE
6 86197670 56023 1 NIPPLE, ¼ X 1.5
7 86272730 66017 1 PLUG, 1/4 BRASS PIPE
8 86247710 56022 1 NIPPLE, 1/4 X 3
9 86197370 31017 2 ELBOW, 1/4 FPT X 1/4 FPT
10 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
11 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
12 86020350 70019 2 SCR, 1/4-20 X 1.25 HHCS SS
13 86200130 151-37C 1 HOSE, PULSE 24.0 1/4 MPT X 1/4 MPT
14 86200940 65227 1 PUMP/MOTOR, 200PSI 230V AC
15 86282310 39699 1 HOSE, 3/8 WIREBOUND X 35”
16 86197550 40014 1 HOSEBARB, 1/4MPT X 3/8 DL
17 86258970 84193 1 VALVE, KNGSTN 3” LVR 500 PSI
18 86197670 56023 1 NIPPLE, 1/4 X 1.5
19 86197760 78308 1 TEE, 1/4 STREET
