2007
Federal Energy
Compliant
5
To Locate a Distributor Near You, Please Visit www.whirlpoolcommerciallaundry.com/distributor, or call 1-800-NO-BELTS
CAM2762TQ
— 27" 2-Speed
Washer with Metercase
Machine Accepts the Following Payment
Systems (not included):
- Coin Slide
- Retrofit Coin Drop
- Retrofit Card Reader
- OPL Push-To-Start Kit (No Coins Needed)
• 3.2 Cu. Ft. Wash Basket, 18 Lbs. UL
• Push Button Controls
• High Efficiency, Low Water Factor
• 3 Cycles: Heavy (Hot/Cold), Permanent
Press (Warm/Cold) and Colorfast (Cold/Cold)
to Provide the Right Washing Conditions
for a Wide Range of Fabrics
• Two‑Speed Advantage with True Gentle
Wash, High Speed Spin Only!
• Deep Rinse System, Automatic
Temperature Control 115º H 85º W
• Porcelain Top and Lid, Rust Proof Stainless
Steel Hinges and Console Screws
• Hidden Lid Switch
• High Speed Spin 640 RPM (Approx.)
• Galvanized, Heavy Gauge Cabinet Back,
Side and Front Panels, Removable Front
Service Panel
• Heavy Duty Motor Coupler Isolator Tested
to 20,000 Cycles! *
• 1 ⁄
2
HP Motor with Built‑In Overload
Protector: 120‑Volt, 60 Hz., A.C. Agitation
Speed 180 SPM/High 120 SPM/Low
• Reliable, Direct‑Drive NO‑BELTS Drive
System, Front and Bottom Serviceable
• Extra Long Power Cord and Commercial‑Grade,
Color‑Coded Water Inlet Hoses with Brass
Couplings and EDPM Rubber Drain Hose
• 3 Cycle Indicator Lamps
• 23.22 Gallons Minimum Water Usage per
Cycle (Low Water Level, 3 Lbs. Load)
• 3 Year Limited Parts Only Warranty **
• Money Acceptors Sold Separately
* Testing complete 11/12/2001
** Call 1‑800‑NO‑BELTS for warranty details
DEEP
RINSE!
Featuring Mechanical Controls
WHIRLPOOL BRAND
COMMERCIAL WASHERS
DIRECT DRIVE SYSTEM
27" heavy-duty commercial
washers feature the
Direct-Drive, No-Belt
washing system for greater
reliability, reduced down
time and increased profits.
LARGE CAPACITY WASH BASKET
Ideal for handling family size loads!
PORCELAIN FINISH
Porcelain top and lid finish resists
rust, chipping and scratching.
FRONT LOCK READY
Factory installed lock
blank provides a visual
vandalism deterrent.
To further discourage theft, order
optional front panel lock assembly
(part #358290) for the added
security of tying the front and top
panels together.
HIGH AND LOW
WATER LEVEL
Reduce water consumption
to 23.22 gallons per cycle!*
*Based on low water level, 3 lb. load
TRIPOD SUSPENSION
Sturdy tripod-suspension
with active liquid filled
balance ring reduces
product weight while balancing
commercial size laundry loads.
RUST PROOF SCREWS
Rust proof Stainless Steel
Torx
® control panel screws
give your machines added
security and service life!
SEALED HIDDEN
LID SWITCH
To help ensure safe
operation, Whirlpool ® commercial
washers feature a lid
switch that is truly hidden. Not only
does this prevent tampering, it
ensures that the washer will not
operate when the lid is open.
INDUSTRIAL
STRENGTH WATER
INLET HOSES
Tested to 1100 PSI!
MEF 1.38
WF 9.0
RMC 51.5%
HIGH EFFICIENCY COMMERCIAL WASHER
