Part Identification ChartÑModel No. WEBE29300
R0800A
M8 x 55mm Bolt (70)Ð1 M10 x 60mm Carriage Bolt (64)Ð2
M10 Large Washer (58)Ð6
M10 Small
Washer (6)Ð18
M8 Nylon Locknut
(54)Ð4
M10 Nylon Locknut
(11)Ð46
M10 x 75mm Bolt (39)Ð2
M10 x 30mm Bolt (38)Ð2
M10 x 45mm Bolt (40)Ð3
M10 x 80mm Bolt (41)Ð24
M10 x 25mm Bolt (43)Ð4
M8 x 25mm Bolt (53)Ð2
M8 x 70mm Bolt (30)Ð1
M10 x 65mm Bolt (56)Ð9
M10 x 20mm Bolt (26)Ð2
M10 x 180mm Bolt (76)Ð1
M10 x 70mm Bolt (85)Ð1
M6 Washer (81)Ð4
M6 x 16mm Screw (61)Ð6
M6 x 65mm Screw (62)Ð4
M8 x 16mm Screw (50)Ð2
M8 Flat Washer (67)Ð2
Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the Part List in the center of this manual. The number following the
key number is the quantity needed for assembly. Note: Some small parts may have been pre-attached. If a
part is not in the parts bag, check to see if it has been pre-attached.
