1/8" or 1/4" glazing in a choice of materials set in automotive rubber beading, 20 ½" x 4 ½").
Prepainted aluminum full view sections also available with various choices of glazing materials.
2.07 Weatherstripping
A) Optional factory-installed foam joint seal is available. Optional field-installed exterior
jamb/perimeter seal is available.
2.08 Insulation
A) As specified will be 1-5/8" polystyrene secured in sections and muntins without the use of muntin
clips and pop rivets. Inside backup sheets will be white prepainted (embossed steel), (vinyl).
2.09 Windload
A) Per DASMA 102-2003 and as required by local codes.
2.10 Options
A) Chain hoist or motor operator.
3.01 Install
A) Install the doors in accordance with Wayne-Dalton Corp. instructions and standards. Installation will
be by authorized Wayne-Dalton representative.
©2004 Wayne-Dalton Corp. 8/2003
Models C24 & C20 Specifications
pg.2
PART III- EXECUTION
