This chart is provided to help you identify the small parts used in assembly. The number in parentheses below
each part refers to the key number of the part from the PART LIST near the end of this manual. Note: Some
small parts may have been preattached. If a part is not in the hardware kit, check to see if it has been
preattached.
M8 Locknut (17)
M6 x 16mm Screw (29)
M10 Locknut (33)
M10 x 63mm Bolt (32)
M6 x 38mm Screw (30)
M8 Washer (16)
M10 Washer (34)
M6 Washer (26)
M10 x 137mm Bolt (36)
M8 x 55mm Bolt (18)
M8 x 40mm Bolt (39)
M8 x 42mm Carriage Bolt (37)
M10 x 50mm Bolt (47)
M10 x 19mm Bolt (48)
PART IDENTIFICATION CHART
