CABINET AND DRAWER PARTS
2
For Model: WVP5000SQ0
(White)
8181426
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10106750 Guide, Use & Care
2 W10011500 Drawer Bin,
(Small)
3 W10011610 Drawer Front
& Handle Assembly
(Top)
4 688983 Screw, 8−18 x 5/8
5 3405184 Handle
6 W10113962 Screw,
8−18 x 1−1/4
7 W10011600 Drawer Front
& Handle Assembly
(Middle & Bottom)
8 W10011320 Top
9 W10116604 Screw, 8−18 x 3/8
10 W10011680 Bracket,
Top Support
11 W10011660 Clip, Top Lock
12 W10011410 Drawer Bin,
Large (2)
13 W10011420 Slide, Assembly
14
9740848 Screw, 8−18 x 1/2
15 W10070750 Console Assembly
16 W10070490 Bracket, Console
17
3400893 Screw, 8−18 x 5/8
18 Cabinet
(Not Serviceable)
19 8563585 Leveling Foot
& Nut
20 3359452 Nut, Foot
Following Parts Not Illustrated
and Optional Parts Not Included
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
