Wolf CT15I/S - Manual (Page 3)

Planning Information
New Integrated Induction Cooktop
M O D E L C T 1 5 I / S
Dimensions in parentheses are in
millimeters unless otherwise specified.
3
S P E C I F I C A T I O N S
Overall Cooktop Width 15" (381)
Overall Cooktop Height 3 1 / 2 " (89)
Overall Cooktop Depth 21" (533)
Element Maximum Power 1200 W (front)
1800 W with 3000 W boost (rear)
Maximum Power Output 3600 W
Element Diameters 6 3 / 4 " (171) and 8 3 / 4 " (220)
Minimum Cabinet Depth 22 3 / 4 " (578)
Minimum Height Clearance* 4 1 / 2 " (114)
Cooktop Cut-Out Width 13 3 / 8 " (340)
Cooktop Cut-Out Depth 19 1 / 4 " (489)
Electrical Supply Requirements 240/208 V AC
50/60 Hz, 20 amp circuit
Conduit 4 ft (1.2 m) flexible 3-wire
Electrical Rating 3.6 kW at 240 V
3.1 kW at 208 V
Shipping Weight 30 lbs (14 kg)
Special Note Cooktop can be installed in combination
with other cooktops or modules
*Minimum 6" (152) clearance is required between countertop and
any combustible surface directly below the cooktop.
Specifications are subject to change without notice.
V E N T I L A T I O N O P T I O N S
30" (762) Cooktop hood or Pro
wall or wall chimney hood or liner
30" (762) or 45" (1143) downdraft
ventilation system
36" (914) Pro island hood
For additional information, refer to the
Cooktop or Pro Ventilation sections of our
website, wolfappliance.com.
A C C E S S O R I E S
Filler strip
Bracket supports for installation
of two integrated modules with
downdraft (Model DD30 only)
Accessories are available through your
Wolf dealer. To obtain local dealer
information, visit the Showroom Locator
section of our website, wolfappliance.com.
Model CT15I/S
Unit dimensions may vary by ± 1 / 8 " (3).
