Use only genuine Walker ® replacement parts. Effective Date 07-01-06
44
ITEM PART DESCRIPTION LOCATION NO.
NO. NO. REQ’D
DECK WELDMENT REPLACEMENT PARTS
NOTE: All parts listed in this section are for Weld-On Repair; Cutting, Grinding, and Welding are required to replace these parts.
DSD52 & DSD62 Weldments
1 8733-3 Rim Rod, RH Rear (20-3/4) DSD52 1
8751-2 Rim Rod, RH Rear (28-3/8) DSD62 1
2 8760-2 Rear Deck Pin (3/4 x 5-3/4) DSD52, DSD62 & DSD74 2
3 8733-63 Rim Rod, LH Rear (28-3/4) DSD52 1
8751-3 Rim Rod, LH Rear (34-3/8) DSD62 1
4 8733-5 Rim Rod, LH Front (22-7/8) DSD52 1
8751-4 Rim Rod, LH Front (28-5/16) DSD62 1
5 8760-1 Front Deck Pin (3/4 x 7-5/8) DSD52 & DSD62 2
6 8733-61 Rim Rod, Front Center (26-5/8) DSD52 1
8751-5 Rim Rod, Front Center (29-1/4) DSD62 1
7 8733-10 Rim Rod, RH Front (16-1/4) DSD52 1
8751-6 Rim Rod, RH Front (19-1/4) DSD62 1
DSD56 Weldments
8 6752-1 Deck Cap Strip, 56SD Rear (33-5/16) DSD56 1
9 5760-4 Rear Deck Pin (5/8 x 5-3/8) All Decks Except DSD52, DSD62 & DSD74 2
10 6752-6 Deck Cap Strip, 56SD LH (39") DSD56 & DSD74 1
11 5760-7 Front Deck Pin (5/8 x 5-3/4) DSD56 2
12 6752-4 Deck Cap Strip, 56SD Front (42") DSD56 1
DSD74 Weldments
9 8760-2 Rear Deck Pin (3/4 x 5-3/4) DSD52, DSD62 & DSD74 2
11 7865-18 Front Deck Pin (3/4 x 6-5/8) DSD74 2
13 8751-7 Rim Rod, LH DSD74 1
14 8751-8 Rim Rod, Front (13-1/2) DSD74 1
DGHS Weldments
9 5760-4 Rear Deck Pin (5/8 x 5-3/8) All Decks Except DSD52, DSD62 & DSD74 2
11 5760-3 Front Deck Pin (5/8 x 5-3/4) All Decks Except DSD52, DSD56, DSD62 & DSD74 2
15 5751-3 Deck Cap Strip, GHS LH (43-3/4) DGHS36 1
5751-1 Deck Cap Strip, GHS LH (49-3/8) DGHS42 1
7701-10 Edge Stiffener, Side (42-3/8) DGHS48 2
16 7701-11 Edge Stiffener, Front (21-7/8) DGHS48 1
17 5751-4 Deck Cap Strip, GHS RH (47-5/8) DGHS36 1
5751-2 Deck Cap Strip, GHS RH (49-3/8) DGHS42 1
DSD & DML Weldments
9 5760-4 Rear Deck Pin (5/8 x 5-3/8) All Decks Except DSD52, DSD62 & DSD74 2
11 5760-3 Front Deck Pin (5/8 x 5-3/4) All Decks Except DSD52, DSD56, DSD62 & DSD74 2
18 5702-6 Deck Cap Strip, (47") DSD36 1
5751-5 Deck Cap Strip, 42" SD LH (47") DSD42 1
19 5751-6 Deck Cap Strip, 42" SD Front (3-9/16) DSD42 1
20 5751-11 DML42A Edge Stiffener DML42A 2
21 5751-12 DML42A Front Stiffener DML42A 1
22 5751-14 DML42A Deck Cap Strip/RH DML42A 1
23 5751-13 DML42A Deck Cap Strip/LH DML42A 1
