16
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
Use only genuine Walker ® replacement parts. Effective Date 07-01-06
DML42A DECK ASSEMBLY (P/N 5707-1)
Gearbox and Drive Components
1 8618-1 Cover, PTO Shaft Guard 1
2 8619 PTO Shaft Guard 1
8618 PTO Shaft Guard Assembly *
(Includes Items # 1, 2, F002 & F025)
3 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1
(Includes Items # 21, F069 & F295)
4 7275-16 U-Joint Tube Assy, Spline 1
5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1
(Includes Item # F076)
6 5704-55 42" Mulch Gearbox 1
Tube Assembly, Cast Iron
(Includes Items # 7-16, F136, F179 & F229)
7 6054 Spline Coupling 4
8 P007 Gasket, Cap (Peerless #788030) 4
9 5063 Gearbox Connector Tube (8-5/8) 1
10 6732-3 Connecting Shaft (6-1/4) 1
11 5052-8 Heavy Duty Gearbox (LH Rotation) 1
12 5704-1 Gearbox Cover Support 2
13 5051-6 Heavy Duty Tee Gearbox, Shear 1
14 6732-1 Connecting Shaft (2") 1
15 5062 Gearbox Connector Tube (4-3/8) 1
16 5053-8 Heavy Duty Gearbox (RH Rotation) 1
17 5052-3 1.375 x .750 x .187 Washer 4
18 5747-11 Rubber Mat (3 x 6) 2
19 5785-5 42" Gearbox Cover 1
(Includes Item # 18)
20 5830 Grease Fitting 1
21 8067-13 Shear Pin w/Cotter (Set of 5) *
(Includes Item # F069)
Deck Housing Components
22 8670 Tilt-Up Hook 1
23 9772 Roller Wheel Assembly (2-1/2) 2
(Includes Item # F059)
24 8490 Roller Wheel Axle Bolt 2
25 NS Deck Serial Number Plate 1
26 5705-28 Blade 22" Mulch 2
5705-19 DML42A Blade Set W/Hubs *
(Includes Items # 27, F002 & F202)
27 5706 Blade Hub & Trash Guard 2
28 8735-10 Rubber Mat (5 x 6) 2
29 7775-1 Hitch Pin, LH (Silver) #6 2
30 8788-1 Rubber Mat (1 x 2) 1
31 5701-11 DML42A Deck Housing 1
(Includes Items # 28 & 30)
32 7775-2 Hitch Pin, RH (Gold) #6 2
33 5727-1 Washer Shim (5/8 ID) 4
Fasteners
F002 10-24 Keps Nut 6
F004 1/4-20 Keps Nut 2
F013 3/8-16 Whiz Locknut 2
F018 5/8-18 Hex Nut 2
F025 10-24 x 3/8 PPHMS 2
F029 1/4-20 x 1/2 Hex Bolt 2
F038 3/8-16 x 1 Hex Bolt 4
F050 1/4 SAE Washer 4
F056 5/8 Split Lock Washer 2
F059 3/8 Wave Spring Washer 2
F069 3/32 x 1/2 Cotter Pin 1
F076 3/8-16 x 5/8 SQH Set Screw *
F136 AN960C416L Washer 16
F179 1/4-20 x 1 Hex Bolt 4
F202 10-24 x 5/8 SHC Screw, GR5 SS 4
F206 #2 x 3/16 Drive Pin 2
F211 1/4-20 x 7/8 Hex Bolt 12
F229 C-Clip (13/16) 4
F246 1/4-20 x 1/2 PTHMS 2
F278 3/8 Split Lock Washer 4
F295 3/16 x 1-1/2 Split Spring Pin 1
F403 1/4-20 x 1/2 PTHMS SS 2
* Service Part Only
NOTE: Order Item # 4 to use the splined deck PTO shaft with
Model MT, MD, MC and MW.
NOTE: Order Item # 5 to use the splined deck PTO shaft with
Model MS and MB.
