S E R V I C E
Whirlpool Europe ADG955WHM 19.03.1998 / Page 5
Customer Service 8542 955 10310 Doc. No: 4812 718 13129
Spare part list
Model ADG 955 WHM
Service No. 854295510310
Version 854295510310
Pos. No. 12NC Code Description
003 0 4812 440 19382 Traverse
004 0 4812 440 18952 Drip tray assy
004 1 4812 401 18402 Holder
011 0 4812 505 18369 Foot long
011 1 4812 528 98004 Shaft flexible
011 2 4812 528 78032 Slide disc f.foot
011 3 4812 535 98054 Gear
011 4 4812 528 98001 Roll f.foot
022 0 4812 440 19398 Side panel left
022 1 4812 440 19397 Side panel right
022 2 4812 440 18953 Spacer
024 0 4812 440 19401 Panel, rear
040 1 4812 417 18774 Hinge left
040 2 4812 417 18773 Hinge right
044 0 4812 492 38362 Spring f.door
044 1 4812 492 38364 Spring f.cap
047 0 4812 404 48591 Brake f.door
047 1 4812 401 18397 Band,brake
047 2 4812 404 68023 Hook
053 0 4812 440 88884 Plinth
103 0 4812 440 18986 Door outer
105 0 4812 404 48611 Fastener door
105 2 4812 505 68004 Clip
120 0 4812 440 19456 Door,inner
120 1 4812 440 18955 Batten
130 0 4812 417 58361 Tilt lock
131 0 4812 401 18416 Hook lock
175 3 4812 466 68532 Batten
191 0 4812 466 68534 Gasket door
192 0 4812 466 68467 Gasket, door lower
200 0 4812 418 18207 Container cpl.
241 0 4812 458 18912 Basket upper straight
241 1 4812 458 18324 Holder cups right white
241 3 4812 528 88068 Wheel,basket upper (set)
241 8 4812 466 68553 Spacer cap set
242 0 4812 458 18923 Basket lower cpl.
242 1 4812 528 88069 Wheel,basket lower
242 2 4812 458 18262 Plate,support f.basket lower
242 3 4812 458 18275 Plate,support f.basket lower
242 4 4812 466 48059 Striker
243 0 4812 458 18272 Basket cutlery
243 4 4812 458 18317 Bracket
261 0 4819 462 38271 Rail telescope, inner
261 1 4819 404 48819 Cap rail
261 2 4812 462 78995 Cap rail ahead
263 0 4819 520 18013 Ball cage cpl.
263 1 4812 520 48001 Ball Niro 8 D
265 0 4812 404 48637 Basket adjustm. cpl.
265 2 4812 404 48638 Grip basket adjustment
301 0 4812 453 70039 Control panel WH
303 1 4812 460 38055 Plate,handle WH
305 0 4812 440 19436 Batten WH
305 1 4819 502 18241 Screw synthetic
305 2 4819 505 18191 Nut
305 3 4812 440 19348 Batten adjustable 5mm WH
Pos. No. 12NC Code Description
305 4 4812 440 19349 Batten adjustable 10mm WH
322 0 4812 453 70038 Insert panel WH
331 0 4812 413 58888 Knob program cpl. WH
331 1 4812 325 88001 Ring knob WH
332 0 4812 410 28564 Push button cap WH
350 0 4812 276 58075 Display board (DB)
400 0 4812 361 58126 Motor + spraypump cpl.
405 0 4812 360 18371 Spray pump
405 1 4819 515 28158 Gasket
420 0 4812 121 18132 Capacitor
421 0 4812 121 18161 Interf.filter
430 0 4812 360 18357 Pump,draining
430 1 4812 466 68506 Shaft seal
450 0 4812 259 28684 Heating element
480 0 4812 321 28386 Cable harness set
480 1 4812 321 28371 Cable
480 2 4812 321 28383 Cable 6poles
480 3 4812 401 18418 Protector f.wiring
490 0 4819 321 18136 Cable,mains 2m
490 1 4812 321 28367 Strain relief
521 0 4812 214 78192 Control board (CB)
531 0 4812 273 18055 Switch waterhardness
531 1 4812 273 18056 Wheel,fingertip
571 3 4812 281 28363 Valve f.zone-washing
575 0 4812 281 28361 Regen.valve
583 0 4812 271 28355 Switch diaphragm
616 0 4812 281 18047 Contact,reed salt
620 0 4812 218 38065 User board (UB)
623 0 4812 271 38356 Microswitch
633 0 4812 271 38355 Microswitch
680 0 4812 418 68154 Combidosage
680 1 4812 466 68495 Gasket
681 1 4812 466 68497 Gasket
681 2 4812 440 18975 Flap
682 0 4812 466 68496 Gasket
691 0 4812 282 68012 Feeler NTC
700 0 4812 530 28804 Hose, inlet aqua stop 4,2m
700 0 4812 530 28848 Hose, inlet aqua stop 2m
700 1 4812 480 48019 Sieve
700 2 4812 520 58002 Gasket set
701 1 4812 310 18153 Yoke clamp set
701 2 4819 401 18423 Holder
710 0 4812 418 68128 Monoblock
710 2 4819 310 38536 Nut threaded ring set
710 3 4819 466 69562 Gasket set
714 0 4812 462 78993 Threaded cap
714 2 4812 440 18963 Cabinet non-return flap
716 0 4812 418 68147 Reg.dosage
716 1 4812 466 68475 Gasket
716 2 4812 462 78994 Cover
721 1 4812 360 68059 Arm,spray lower cpl.
721 2 4812 466 68491 Gasket 25x2,3B
721 3 4812 466 68558 Gasket 30x3,0
721 4 4812 440 19455 Flange
722 0 4812 360 68044 Arm,spray upper
