Base Diagram
CONTROL
UNIT
DETAIL
TO RECEIVER
DO NOT USE
AZ MOT
O
R
EL
MOT
O
R
8-PIN
POWER T A
LIMIT SWITCHES
PROGRAMMING PORT (F
ACT
O
RY
USE
ONL
Y)
BACK OF
VEHICLE
FRONT OF VEHICLE
GPS ANTENNA
CONTROL
UNIT
#1 POWER
SUPPLY
REFLECTOR
TO PRIMARY
RECEIVER
TO LNBF
AZ MOTOR
TO +12 VDC
POWER SOURCE
EL MOTOR
GROUND
BLOCK
TO SECOND
RECEIVER
AZ
EL
SWITCHES
FIGURE 9
CONTROL UNIT
(DETAIL BELOW)
#3 CONTROL
UNIT TO LNBF
#4 COAX CABLE
AT CONTROL
UNIT GOING TO
HEYCO
#2 LNBF
VOLTAGE
