FEATURES & OPERATING CONTROLS (continued)
5
504
p/n
3039
03
o
p
M
W
V
-4H V
entle
ss Ho
tpla
te Coo
k
top
ITEM
V1
V2
V3
V4*
V5*
V6*
H1
H2
H3
H4
H5
W.01
W.02
W.03
W.04
W.05
W.06
W.07
W.08
W.09
DESCRIPTION
POWER SWITCH
POWER ON INDICATOR
CHECK FILTERS ALARM
INDICATOR
REPLACE PREFILTER
ALARM INDICATOR
REPLACE FILTER PACK
ALARM INDICATOR
SERVICE REQUIRED
ALARM INDICATOR
LEFT FRONT HOTPLATE
CONTROL
LEFT REAR HOTPLATE
CONTROL
RIGHT REAR HOTPLATE
CONTROL
RIGHT FRONT HOTPLATE
CONTROL
POWER ON INDICATOR
TEMPERATURE CONTROL
POWER ON INDICATOR
THERMOMETER (optional)
HUMIDITY CONTROL
DRAWER CATCH
DRAWER STOP
DRAWER ROLLERS
POWER SWITCH (RWT)
CONTROLLER
COMMENT
Energizes blower motor. If, after 10 seconds, proper
conditions are met, cooktop is energized.
GREEN. Glows when POWER switch is ON.
AMBER. Glows if one or more filters are out of position. Check
all filters and baffles for proper installation.
AMBER. Glows when PREFILTER is approaching the end of its
service life and must soon be replaced.
AMBER. Glows when FILTER PACK is approaching the end of
its service life and must soon be replaced.
RED. Glows when PREFILTER and/or FILTER PACK has
reached the end of its service life and is too loaded to allow
sufficient air flow. Filter MUST be replaced. Appliance is SHUT
DOWN until expended filters are replaced.
Infinite switch control of temperature of one hotplate section.
Infinite switch control of temperature of one hotplate section.
Infinite switch control of temperature of one hotplate section.
Infinite switch control of temperature of one hotplate section.
AMBER. Glows when temperature control is turned ON.
Infinite switch control of temperature of one warmer drawer.
AMBER. Glows when associated temperature control is turned ON.
Reads temperature inside drawer cavity
Must be ordered at time of initial build.
Slide control of shutters to control air circulation within the warmer
drawer.
Holds drawer closed.
Prevents drawer from opening too far. Spring loaded to permit easy
removal of drawer.
Support drawer and allow it to open and close smoothly.
Energizes unit (RWT-style only)
Controls cavity temperature. Readout displays setpoint and actual
temperature information. UP ARROW / DOWN ARROW keys allow
modification of setpoint temperature. (RWT-style units only)
COOKTOP SECTION CONTROLS
OPTIONAL WARMER SECTION CONTROLS
VENTILATOR SECTION CONTROLS
