Weider Pro 260 831.15609.0 - Manual (Page 10)

10
57
34
2
8
11
15
37
35
17
ATTACHING THE LAT BAR
Attach the Lat Bar (17) to the Lat Cable (35) with a
Cable Clip (37). Remove the Lat Bar when performing
an exercise that does not require it.
ATTACHING THE CURL PAD
For some exercises, the Curl Pad (15) must be
attached to the weight bench. Remove the 45mm
Thick Square Inner Cap (57) from the Front Leg (2).
Insert the Curl Post (11) into the Front Leg (2). Align
one of the adjustment holes in the Curl Post with the
adjustment hole in the Front Leg. Fully tighten the
Curl Knob (34) into the Front Leg.
The Lat Tower (8) can be attached in the same way.
Note: When the Curl Pad (15) or Lat Tower (8) is not
in use, the 45mm Thick Square Inner Cap (57) should
be inserted into the Front Leg (2).
