Weil-McLain 88 Water and Steam Boilers — Series 2 —
For Gas, Light Oil, & Gas/Light Oil-Fired Burners
4
Part No. 550-142-026/0508
Dimensions in Inches
Burner
Model
Number
Air Tube
Combination
A
B
C
D
E
F
G
H
I
Overall
Length
Insertion
Depth
Maximum
Tube O.D.
Burner
Length
(External To
Appliance)
Overall
Height
Bolt
Circle
Centerline
To Pump
Centerline
To Motor
Square
Flange
Width &
Height
CF1400-W
CF66KD
24.75
4.00
5.50
20.63
13.50
10.25
9.50
9.82
12.00
CF2300A-W
CF66KG
25.25
4.00
6.50
21.13
15.60
10.25
10.40
12.00
12.00
CF2300A-W
CF66KS
25.25
4.00
8.13
21.13
15.60
10.25
10.40
12.00
12.00
CF2500-W
CF66KP
26.25
4.00
6.50
22.13
17.70
10.25
12.70
14.10
12.00
CF3500A-W
CF80KM
27.50
4.50
7.87
23.38
17.70
10.25
12.70
14.10
12.00
Burner dimensions
