Weil-McLain 88 Water and Steam Boilers — Series 2 —
For Gas, Light Oil, & Gas/Light Oil-Fired Burners
2
Part No. 550-142-026/0508
Burner data
Table 1
Boiler
Model Number
Burner Input (Forced
Draft) No. 2 Oil
Low Fire Firing Rate
No. 2 Oil
Positive Pressure
in Firebox
Standard
Burner Model
Designation
Becket
Part Number
for Ordering
GPH
GPH
Inches W.C.
488R
6.90
4.90
0.60
CF1400-W
WL 7001
488
7.00
5.00
0.60
CF1400-W
WL 7001
588
9.40
6.8
0.60
CF2300A-W
WL7101
688
11.80
8.51
0.65
CF2300A-W
WL7102
788
14.20
10.41
0.65
CF2300A-W
WL7103
888
16.60
8.30
0.65
CF2500A-W
WL7201
988R
17.20
11.60
0.65
CF2500A-W
WL7202
988
18.80
9.53
0.65
CF2500A-W
WL7202
1088R
20.00
9.54
0.65
CF2500A-W
WL7301
1088
21.50
11.26
0.65
CF2500-W
WL7301
1188
23.50
12.30
0.65
CF2500-W
WL7302
1288
26.00
13.00
0.65
CF3500A-W
WL7401
1388
28.50
15.00
0.70
CF3500A-W
WL7402
Boiler
Model Number
Standard
Combustion Control
Air Tube
Combination
Starting
Head Setting
Approximate Air Settings
Low Fire
High Fire
488R
Beckett 7505P1515/CC
CF66KD
4
39
54
488
Beckett 7505P1515/CC
CF66KD
4
39
54
588
Beckett 7505P1515/CC
CF66KG
0
34
42
688
Beckett 7505P1515/CC
CF66KG
3
41
51
788
Beckett 7505P1515/CC
CF66KG
6
43
54
888
Beckett 7505P1515/CC
CF66KP
2
25
50
988R
Beckett 7505P1515/CC
CF66KP
4
28
54
988
Beckett 7505P1515/CC
CF66KP
4
27
52
1088R
Honeywell RM7840M
CF66KP
8
29
59
1088
Honeywell RM7840M
CF66KP
8
29
59
1188
Honeywell RM7840M
CF66KP
3
29
44
1288
Honeywell RM7840M
CF80KM
3
31
63
1388
Honeywell RM7840M
CF80KM
6
33
98
Burner specifications and settings
