7
7. With the cabinet installed, the air cleaner can now be
wired to electrical input source.
WARNING
!
Installation of this unit must comply with local Installation of this unit must comply with local Installation of this unit must comply with local Installation of this unit must comply with local Installation of this unit must comply with local
electric codes or other applicable codes.
electric codes or other applicable codes. electric codes or other applicable codes. electric codes or other applicable codes. electric codes or other applicable codes.
Review and understand local codes prior to instal- Review and understand local codes prior to instal- Review and understand local codes prior to instal- Review and understand local codes prior to instal- Review and understand local codes prior to instal-
lation.
lation. lation. lation. lation.
Failure to do so could result in serious personal Failure to do so could result in serious personal Failure to do so could result in serious personal Failure to do so could result in serious personal Failure to do so could result in serious personal
injury or death.
injury or death. injury or death. injury or death. injury or death.
8. An air cleaner unit with no air flow monitor requires
electrical wiring through the furnace controls. Connect
wiring to the furnace control terminals (EAC-H) for
power, (EAC-N) for neutral and connect metal frame of
EAC to ground.
If the air cleaner unit has an air flow monitor, it must be
connected to 120 VAC 60 Hz. A 20 amp circuit is more
than adequate. If an air flow monitor is not installed but
is required for operation, order Air Flow Kit F859-0381.
If a power cord is required, order F97-0019.
9. Remove junction box cover and install the required
bushing into the 3/4 in. Knock out. With the supply
voltage turned off, route three (3) wires into junction
box for connections. (See Fig. 17.)
Insure all wires are clamped, wire connectors prop-
erly installed and grommets used to prevent wire
abrasion.
Vertical
Section
Wood Block
Tape All
Joints
Figure 16
Hot
Neutral
Grounding
Conductor
Front View
Figure 17
Floor
Conduit
Duct
Electronic
Air Cleaner
Figure 18
Cabinet
Pre-Filters
Handle
Contact
Button
Contact
Button Collecting Cells
Power Pack
Figure 19
WIRING INSTRUCTIONS WIRING INSTRUCTIONS WIRING INSTRUCTIONS WIRING INSTRUCTIONS WIRING INSTRUCTIONS
10. With the cabinet Installed, reinstall pre-filter(s) and
collecting cell(s) (Figure 19).
NOTE: The contact button and handles on the cell
must be facing you and ionizing wires must be on the
air intake side.
11. Install the power pack as follows:
Engage the lip on lower inside edge of power pack in
the flange on cabinet and carefully close the power
pack, making sure that the electrical connector prongs
on the power pack enter the slots in the socket on
cabinet. When the power pack is fully in place, en-
gage the latch and snap it closed.
