Parts List – Saw Head - Model 7060 Semi-Automatic Cut-Off Band Saw
Ref Part
No. Number Description Qty
146 5512248 Bearing, Thrust (51194NJK) 1
147 5512249 Indicator, Tension 1
148 5512250 Washer, Flat 1
149 5512251 Washer, Special Spring 18
150 5512252 Bracket, Slide 1
151 5512253 Washer, Lock 3
152 5512254 Screw, Hex Cap 3
153 5512255 Screw Assembly 3
154 5512126 Screw, Set (M6X10) 1
155 5512256 Nut, Hex (M16) 1
156 5512257 Screw, Hex Cap, Socket 1
(M12X25)
157 5512128 Washer (M12) 1
158 5512259 Bracket, Slide 1
159 5512260 Gib 2
160 5512261 Shaft, Blade Wheel Bracket 1
161 5512146 Screw, Hex Cap, Socket 6
(M8X20)
162 5512156 Washer, Lock (M8) 6
163 5512263 Shaft, Tension 1
164 5512264 Bar, Extension 1
165 5512265 Key (5X5X20) 1
166 5512266 Wheel, Handle 1
167 5512267 Screw, Set (M8X10) 1
168 5512268 Head, Connection 1
169 5512269 Clamp, Hose 5
170 5512270 Gear Box Assembly 1
171 5512271 Motor 1
172 5512272 Key (8X8X40) 1
173 5512273 Key (7X7X45) 1
174 5512274 Seat, Support Bracket 1
175 5512156 Washer, Lock (M8) 3
176 5512275 Belt (1922V321) 1
177 5512276 Bolt, Hex Cap (M8X16) 3
178 5512277 Variable Speed Assembly 1
179 5512278 Knob (3/8 In.) 1
180 5512279 Washer 1
181 5512280 Cover, Pulley 1
182 5512281 Pulley, Gear Box 1
183 5512282 Shaft 1
184 5512283 Plate, Variable Speed 1
185 5512284 Plate 2
186 5512167 Washer (M8) 3
Ref Part
No. Number Description Qty
190 5512285 Box Assembly, Blade Wheel 1
191 5512149 Washer, Lock (M10) 4
192 5512287 Bolt, Hex Cap (M10X35) 4
193 5512288 Hose (30MM) 1
194 5512192 Bolt, Hex Cap (M12X35) 4
195 5512129 Washer, Lock (M12) 4
196 5512291 Nozzle, Flexible 1
197 5512292 Guide, Blade 1
198 5512293 Knob 2
199 5512294 Bolt, Stand 1
200 5512295 Nut, Hex (1/4 In.) 1
201 5512296 Clamp, Hose 2
202 5512297 Bracket, Blade (Left) 1
203 5512128 Washer (M12) 4
204 5512299 Bolt, Hex Cap (M12X30) 4
205 5512300 Bolt, Hex Cap (M6X12) 2
206 5512301 Washer, Lock (M6) 2
207 5512302 Bracket, Blade (Right) 1
208 5512167 Washer (M8) 6
209 5512156 Washer, Lock (M8) 6
210 5512304 Seat, Wire Brush 1
211 5512680 Brush, Wire 1
212 5512306 Washer (M6) 1
213 5512107 Blade 4/6 TPI (Standard) 1
5512108 Blade 6/10 TPI 1
214 5512308 Screw, Hex Cap, Socket 4
(M10X45)
215 5512149 Washer, Lock (M10) 4
216 5512140 Washer (M10) 4
217 5512311 Washer 1
218 5512312 Screw 1
219 5512192 Bolt, Hex Cap (M12X35) 2
220 5512314 Screw, Set (M8X10) 4
221 5512315 Bracket, Adjustable Mount 1
(Right)
222 5512316 Bracket, Adjustable Mount 1
(Left)
223 5512317 Block, Lock 2
224 5512318 Screw, Set (M8X16) 8
225 5512319 Handle, Locking (3/8X2 In. 2
226 5512140 Washer (M10) 2
227 5512321 Scale, Angle 1
228 5512322 Screw, Pan Head (M5X8) 4
Ref Part
No. Number Description Qty
229 5512323 Screw, Hex Cap, Socket
(M10X25)
2
230 5512324 Bracket, Side 1
231 5512325 Wheel, Idler 1
232 5512326 Bearing, Ball (6206Z) 3
233 5512327 Washer (M12X35W) 1
234 5512328 Bolt, Hex Cap (M12X25) 4
235 5512329 Guard, Blade 1
236 5512330 Bracket, Guide (Left) 1
237 5512331 Screw, Hex Cap, Socket 1
(M8X30)
238 5512332 Bearing, Ball 4
239 5512333 Screw, Hex Cap, Socket 4
(M6X16)
240 5512684 Rear Blade Guide, Left 1
241 5512683 Front Blade Guide, Left 1
242 5512678 Assembly, Eccentric Shaft 2
242A 5512337 Screw, Cap (M8X40) 4
242B 5513861 Bearing, Ball (6201ZZ) 8
242C 5517141 Bushing, Eccentric Shaft 2
243 5512340 Shaft 2
244 5512341 Spring 2
245 5512342 Knob, Adjusting 2
246 5512343 Wheel, Drive 1
247 5512344 Washer (M12 X50MM) 1
248 5512345 Screw 1
249 5512346 Bracket, Guide (Right) 1
250 5517140 Bushing, Center Shaft 2
251 5512686 Rear Blade Guide, Right 1
252 5512685 Front Blade Guide, Right 1
253 5512350 Cover, Blade Wheel (Right) 1
254 5512222 Screw, Pan Head (M6X15) 4
255 5512351 Screw, Hex Cap, Socket 2
(M6X12)
256 5512160 Washer, Lock (M6) 2
257 5512306 Washer (M6) 2
258 5512221 Handle 2
259 5512354 Guard, Wire Brush 1
260 5512355 Screw (1/4X3/8) 6
261 5517143 Assembly, Center Shaft 2
