White Mountain VSR-18-1 - Manual (Page 15)

14015-1-0903 Page 15
Index Part
No. Number Description
Index Part
No. Number Description
COMMON PARTS
1
15426 REAR LOG SUPPORT (18)
1 15427 REAR LOG SUPPORT (24)
1 15428 REAR LOG SUPPORT (30)
2 11376 BURNER SUPPORT - LEFT
3 P-271 ORIFICE FITTING
5 R-5675 AIR SHUTTER-LPG
5 R-5676 AIR SHUTTER-NAT
6 15415 PILOT BRACKET
7 R-7158 PILOT ASSEMBLY-NAT
7 R-7157 PILOT ASSEMBLY-LPG
8 14033 BURNER ASSEMBLY (18)
8 14035 BURNER ASSEMBLY (24)
8 14037 BURNER ASSEMBLY (30)
VSR-18,24,30
4
P-265 ORIFICE-LPG (18) (40,000 BTU)
4 P-209 ORIFICE-NAT (18) (40,000 BTU)
4 P-256 ORIFICE-LPG (18) (65,000 BTU)
4 P-274 ORIFICE-NAT (18) (65,000 BTU)
4 P-257 ORIFICE-LPG (24&30) (75,000
BTU)
4 P-276 ORIFICE-LPG (24) (50,000 BTU)
4 P-279 ORIFICE-NAT (24&30) (75,000
BTU)
4 P-280 ORIFICE-NAT (24) (50,000 BTU)
4 P-181 ORIFICE-LPG (30) (60,000 BTU)
4 P-283 ORIFICE-NAT (30) (60,000 BTU)
9 11375 BURNER SUPPORT - RIGHT
10 R-7155 GAS VALVE - LPG
10 R-7156 GAS VALVE - NAT
NS R-7195 BRASS MALE CONNECTOR
NS R-5910 SWITCH LOG ASSEMBLY
NS R-5699 WIRE HARNESS
NS R-5757 ON/OFF SWITCH
NS 15432 TUBING VALVE TO PILOT
NS 15430 TUBING VALVE TO BURNER
NS 15496 ROCK WOOL
NS 11788 DECORATIVE ROCK
NS R-2809 DAMPER CLAMP
NS R-734 LIGHTER ROD
NS R-1054 THERMOPILE
VSM-18,24,30
5
P-265 ORIFICE-LPG (18) (40,000 BTU)
4 P-211 ORIFICE-NAT (18) (40,000 BTU)
4 P-256 ORIFICE-LPG (18) (65,000 BTU)
4 P-273 ORIFICE-NAT (18) (65,000 BTU)
4 P-257 ORIFICE-LPG (24&30) (75,000
BTU)
4 P-276 ORIFICE-LPG (24) (50,000 BTU)
4 P-277 ORIFICE-NAT (24&30) (75,000
BTU)
4 P-278 ORIFICE-NAT (24) (50,000 BTU)
4 P-281 ORIFICE-LPG (30) (60,000 BTU)
4 P-282 ORIFICE-NAT (30) (60,000 BTU)
11 11481 BURNER SUPPORT - RIGHT
12 15413 REGULATOR MOUNTING
BRACKET
13 R-7159 INLET REGULATOR - LPG
13 R-7160 INLET REGULATOR - NAT
14 P-133 NIPPLE 2"
15 P-135 3/8" ELBOW
16 P-239 NIPPLE 1 1/2"
17 R-7195 BRASS MALE CONNECTOR
18 R-7278 GAS VALVE
19 15494 COVER PLATE
NS 15431 TUBING VALVE TO PILOT
NS 15429 TUBING VALVE TO BURNER
NS 15496 ROCK WOOL
NS 11788 DECORATIVE ROCK
NS R-2809 DAMPER CLAMP
NS R-734 LIGHTER ROD
NS R-2256 THERMOCOUPLE
PARTS LIST
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
