Windsor Sensor XP12 User Manual
Page 15
PARTS LIST / SENSOR XP12 / 230/240V
POS
PRODUCT
CODE
PRV NO.
DESCRIPTION
100
86144330
5485WI
POWER HEAD COVER XP 12
101
86141430
5008BLU
EXHAUST FILTER CATCH
102 86141450
5143 EXHAUST
FILTER
103
86141410
5007BLU
EXHAUST FILTER COVER
104
86146160
5729UL
SWIVEL NECK ASSEMBLY
105
86143210
5495UL
MALE CONTACT HOLDER
106
86147030
0102
SCREW M3,9x13 MM DIN 7981
107 86139230
2494 CABLE
CLAMP
108
86145120 5101
SLEEVE
109
86146090
5480
SWIVEL NECK SUPPORT RIGHT
110
86146150
5479
SWIVEL NECK SUPPORT LEFT
111
86146130
5717
SWIVEL NECK BEARING
112
86137650
5193ER
12V POWER SUPPLY
113 86144650
5205 RIBBON
CABLE
114
86138650
5102BLU
BRUSH ROLLER RELEASE
115 86145290
5103 SPRING
116
86137980
5051HG
AXLE ASSEMBLY GRY
117
86293260
5059OR
FOOT PEDAL, ORANGE
118 86137990
5053 AXLE
119 86146670
5819HG WHEEL,
GRY
120
86146570
2010
WHEEL RETURN SPRING
121
86140000
2014
CLAMP CONNECTING ROD (AXLE)
122
86138170
5287BLU
BEARING BLOCK RIGHT HAND
123
86004950
5010WI
BRUSH ROLLER SR 12
124
86138940
5005HG
BUMPER SR12 GRY
125
86144730
5155HG
RUBBING PLATE GRY
126
86137720
5172OR
ACCESS DOOR, ORANGE
127
86138000
5303
ACCESS DOOR AXLE
128
86145330
5304
ACCESS DOOR SPRING
129 86142560
5154HG HINGE
GRY
130
86147150
0100
SCREW 2,9x9,5
131
86147170
0176
SCREW AM 4 X 30
132
86143920
5174HG
PILE ADJUSTMENT WHEEL GRY
133
86145080
5060ER
SERVO MOTOR WITH GEAR BOX
134 86138280
5411HG BOTTOM
PLATE
135
86138300
5412HG
BOTTOM PLATE SR12
136
86144940
5400-1
SEALING STRIP 12”
137
86146790
5401
WIRE TIE, BOTTOM PLATE, OUTER
138
86146800
5402
WIRE TIE, BOTTOM PLATE, CENTER
139
86144850
0197
SCR, M4X12 MM W/WASHER
140 86139930
5482HG CHASSIS,
COMPLETE
141
86139410
05118S
CARBON BRUSH SET 230/240V
-
-
5470
VACUUM MOTOR 1000W / 230V
-
86143640
5471
MOTOR 1000W / 240V
142 86144710
5100 RUBBER
MOUNTING
143
86143620
5462
MOTOR PULLEY 2MR
144 86145470
5129 SUPPORT
LEVER
145 86145460
5107 SUPPORT
SPRING
146
86143570
5112SW
MOTOR PULLEY COVER
147
86140160
5740er
COMPUTER CONTROLLER, 115 & 230v
148
86147160
0107
SCREW 2,9x13
149
86147190
0143
WASHER 3,2
150
86140760
5173SW
COVER (SWIVEL NECK)
151
86145060
5464
SENSOR X4 CPL
152
86147050
0104
SCREW M3.9 x 25MM
153 86138240
5463 BELT
2MR-310-6
154
86005000
5110
BELT HTDII, 219 3M
155
86138200
5766HG
BEARING BLOCK L.H. CPL.
156
86016900
0103ER
SCREW C 3,9x16
157
86146550
0141
WASHER, LOCK
158 86143560
5018UL MOTOR
COVER
159 86143580
5117 SENSOR
PULLEY
