Whirlpool 465 - Manual (Page 23)

- 21 -
GAS RANGE STRIP CIRCUITS
K.E.T., EZ-100 & EZ-150 Controls
L1 N
W BK
BK R W
V V
OVEN CONTROL
OVEN CONTROL
TRANSFORMER
SENSOR
BAKE RELAY
BAKE VALVE
BAKE IGNITOR BROIL RELAY
P3-4 P3-1
P1-6 P1-7
P5 P2-1
P2-4
SELF-CLEAN CIRCUIT
L1 N
W BK
BK BU
BR
BU GY
GY Y
W
W
V V
OVEN CONTROL
OVEN CONTROL
TRANSFORMER
SENSOR
BAKE RELAY
BAKE VALVE
BAKE IGNITOR
BROIL RELAY
LATCH RELAY*
P3-4
P4
P3-1
P1-6
(N.O.)
DOOR
SWITCH
DOOR LATCH
SWITCH
LATCH
SOLENOID
P1-5 P1-1
P1-3
P1-7
* PULSE 1 SECOND
P5 P2-1
P2-4
L1 N
W BK
BK BU W
V V
OVEN CONTROL
OVEN CONTROL
TRANSFORMER
SENSOR
BAKE RELAY
BROIL VALVE
BROIL IGNITOR
BROIL RELAY
P3-2 P3-1
P1-6 P1-7
P5 P2-1
P2-2
BROIL CIRCUIT
BAKE CIRCUIT
