Maintenance Instructions
LUBRICATION
38
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Deck Caster Wheel Bearing Grease 2
3 Deck Belt Tensioner Pivot Grease 1
4 Front Deck Lift Pivot Grease 2
5 Rear Deck Lift Pivot Grease 2
6 Pivot Assembly, Tilt-Up Deck Grease 2
7 Deck Support Arm Socket Grease 2
8 Steering Lever Pivot Grease 2
9 Transaxle Oil Reservoir Oil 2
10 Deck-to-PTO Coupling Grease 1
(Grease Slide Area)
11 Deck Support Arm Pivot Grease 2
12 Universal Joint Tube Assembly Grease * 1
13 FSC Lever Pivot Grease 1
14 Hydro Idler Arm Pivot Grease 1
15 Body Latch Oil 2
16 PTO Clutch Lever Pivot Grease 1
17 PTO Belt Tightener Pivot Grease 1
18 Throttle Control Cable Ends Oil 2
19 Choke Control Cable Ends Oil 2
20 Tail Wheel Caster Fork Pivot Grease 2
21 Rear Wheel Pivot Grease 1
22 Rear Wheel Bearing Grease 2
23 Engine / Oil Filler Oil ** 1
24 Parking Brake Pivot Grease 1
25 Choke Control Pivot Oil 1
26 Throttle Control Pivot Oil 1
27 Universal Joint Shaft Assembly Grease * 1
* Grease every eight (8) hours.
** Refer to Engine Oil located on page 35.
