BURNERS Provide cooking heat
Front and rear burners are individually controllable
Removable for easy cleaning
BURNER CONTROL Provide individual control of front and rear burners
KNOBS
PILOT LIGHT Provides ignition source for main burners
ACTUATOR Admits gas to burner when depressed. Actuator head removable for easy
cleaning
GRATE ASSEMBLY Holds food product at proper distance from burner flame
Removable for easy cleaning
DRIP TRAY Catches drippings
Removable for easy cleaning
ADJUSTABLE LEGS Allow for ventilation under hotplate. Provide means of
leveling the appliance, and of cleaning underneath
NAMEPLATE Gives Manufacturer, Model and Serial Number
(on back—not shown) Also provides fuel specifications and agency approval information
FEATURES & OPERATING CONTROLS
Fig. 1 Countertop Gas Hotplate - Features & Operating Controls
2
FRONT
BURNER
FRONT BURNER
CONTROL KNOB
REAR BURNER
CONTROL KNOB
REAR
BURNER
PILOT
BURNERS
ADJUSTABLE
LEGS
DRIP TRAY
GRATE
ASSEMBLY
ACTUATOR
HEADS
M
228 306916
Op
M
H-2412 In
sta
n
t-
On Dual
Pilo
t
Gas
Hotplate
