9
14. Press two 25mm Round Inner Caps (24) into the
ends of the Weight Rests (51).
Insert the Weight Rests (51) into set of holes in
the Uprights (1). Rotate the Weight Rests to the
locked position, with the locking pin wrapped
around the Upright.
15. Wet the ends of the Lat Bar (37) with soapy
water. Slide the two Handgrips (38) onto the Lat
Bar.
16. Make sure that all parts are properly tightened
before you use the weight bench. The use of
all remaining parts will be explained in
ADJUSTMENTS starting on the next page.
24
1
24
51
51 1
15
38
37
38
14
WARNING:
Always insert the
Weight Rests (51) into the Uprights (1) at
the same height.
