12
ATTACHING THE LAT BAR
Attach the Lat Bar (37) to the Cable (39) with a Cable
Clip (41). Rest the Lat Bar on the lat bar rest on the
Lat Tower (40).
37
39
41
Lat Bar
Rest
40
ADJUSTING THE WEIGHT RESTS
The Weight Rests (51) can be adjusted to three
heights. To move the Weight Rests, disengage the
locking pins and remove the Weight Rest from the
Uprights (1). Reinsert the Weight Rests into a set of
holes in the Uprights. Rotate the Weight Rests to the
locked position, with the locking pin wrapped around
the Upright.
51
51
1
1
Locking
Pin
WARNING:
Always insert the
Weight Rests (51) into the Uprights (1) at
the same height.
WARNING:
Always remove
the Lat Bar (37) when performing an exer-
cise that does not require it.
Locking
Pin
