STEP

• Align holes in rear shield (QO3) with
the holes in the brackets on the back side
of the weight stack; secure using 10 bolts
(M5x10). Take the left (QO1) side shield
and repeat on front side of weight stack
tower using six bolts (M5x10). Tighten
interior brackets (B09 & B10). Attach right
side shield (Q02) with six bolts (M5x10).

• Place slip-on nuts over the holes of the
left weight stack tower upright. Snap two
halves of top cover together (QO6 &
QO7). With tallest point facing the rear of
the machine, place the assembled top
covers on top of the weight stack tower
and secure using six screws (M5x15).

LIGHT BLUE BAG
