Page 6 Installation Manual
A Single Wooden Stud
Mounts
B Solid Structure
Mounting Points
C Ceiling Plate
D Allen Wrench
E Height Adjustment
Screws
F Tension Knobs
G Safety Knob
H Security Screws
I Leveling Screws
J Universal Mounting
bracket
K Leg Assembly
L Projector (not included)
M Tri-Lock Opening
NOTE: The four (two-piece)
leg assemblies can be used as
single leg or any
combination of single and
dual legs together as shown
in Options 1 and 2. The
number of legs may vary
depending on the number of
mounting points found on
the bottom of the projector.
D
D
M
H
J
L
L
J
A
B
K
G
E
C
M
I
H
F
Option 2
Option 1
Single Leg
Combination
Leg
