Installation of Wall Mount (Optional)
To obtain a wall-mounting kit, contact ViewSonic or your local dealer. Refer to
the instructions that come with the base mounting kit. To convert your LCD
display from a desk-mounted to a wall-mounted display, do the following:
ViewSonic VX510 5
1 Disconnect Power.
2 Lay the LCD display face down on a towel or blanket.
Attach the mounting bracket from the VESA compatible wal l-mounting kit
(
75 mm x 75 mm distance).
7 Attach the LCD display to the wall, following the instructions in th
e
wall-mounting kit.
6
Remove the Plastic Covers from the back of the LCD display. 3
Remove the five screws attaching the base. 4
Remove the Rubber Plugs from inside the four VESA screw holes. 5
REAR PANEL
COVERS
FIVE BASE SCREWS
FOUR
VESA
SCREW
HOLES
PLASTIC
COVERS
