Door reinstallation – Viking F20481 User Manual
Page 14
27
26
11
Remove screws to remove right and left hinges. Retain
all screws for later use.
5
Replace hinge cover.
6
Replace toe grille.
1
2
Install top hinge loosely with 5/16” hex head screws.
Install center hinge with Phillips screws.
3
4
Place hinge side of refrigerator door on center
hinge pin.
While holding refrigerator door upright, tighten down
top hinge with 5/16” hex head drive.
Door Reinstallation
(Bottom-Mount)
